Cutting

• Automatic cutting machine
• Capacity - up to 500 mm diameter

Ring Rolling

• 700 ton hydraulic forging press - 1 no.
• 500 ton hydraulic forging press - 1 no
• 250 ton hydraulic forging press - 1 no.
• 180 dia electrotherm induction billet heater
• Capacity - 100 mm to 600 mm

Heat Treatment

Type – Continuous

Capacity – 300 tons/month

Process

• Oil quenching
• Water quenching
• Isothermal
• Anneling
• Normalising
• Hardning & Tempering

Machine Shop

• CNC Lathe Machine
• Vertical Milling Machine
• Horizontal Milling Machine-Gear Shaper Fellows 10
• CNC Gear Shaper
• Hardinge Conquest Vt 200
• CNC Grinding Machine
• Hobbing Machine

CMM Coord3 – SK-0018/22

• X Axis - Longitudinal Adjustment of Portal 1.200 MM
• Y Axis - Cross Slide on Portal 850 MM
• Z Axis - Measuring Slide Quill (Vertical) Approx. 600 MM
• Distance Between Columns, 1000 / 1080 MM
• Vertical Daylight, Approx.750 MM
• Measuring Table, 1000 X 2100MM

Metallurgical Microscope

Make :- Banbros

BMI-110B Series Inverted Metallurgical Microscopes is Equipped with Excellent UIS Optical System and Modularization Function Design.

Magnification : 100x, 200x, 500x & 1000x (Optional Upto 2000x)

Universal Testing Machine

Make :- Fie

Model :- UTN-40

Capacity :- 400 KN

Universal Testing Machine Capable To Do Tensile , Compression, Shear & Transverse Testing

BHN Hardnes Tester

Model :- B/3000/H

Make :- Saroj

Qty :- 2 NOS

Impact Testing Machine

Model :- IT-30

Designed For Conducting IZOD, Charpy Test.

The test Methods Confirm to BS:131:Part 4-1972 (Amended 15 Aug. 1993) BSEN:10045-2:1993.

Magnetic Particle Testing Equipment

Capability to Magnetize :- up to 6000AMPS

Voltage :- 415 V

Power Source :- Electric
